API Fields

Fields

APIs

POST

To create a field, assigning it to an existing or new farm.

In order to use this API, the Create Fields feature is required.

Content-Type: application/x-www-form-urlencoded
POST /api/agregarlote

On the form include:

nombre: String, name of the new field.
shape: String, WKT of the polygon. It must be projected in EPSG 4326 (WGS84). For example "POLYGON((-62.31584534415723908 -33.12230490954907935, -62.31855704936425155 -33.12061682816192842, ...))"
idcampo: Int, ID of the Farm to which the new field belongs. In case you want to assign it to a new Farm, use the property namefarm
nombrecampo: String, Field name whose length must not exceed 50 characters. In case of sending idfarm, this property is ignored. If a Farm with the name farmname exists, the field will be assigned to it. Otherwise, a new Farm shall be created.

If the polygon is not available in WKT format but in KML, KMZ or Shapefile format, it is possible to use this API to perform the conversion

Response example:

{
  "res": "ok",
  "info": "New field id 16548",
  "id_lote": "16548",
  "id_campo": 12555
}

Specific errors

code	description
1	General error
2	The `shape` geometry is invalid
3	N/A
4	The name of the field is repeated in the farm
5	N/A
6	Length of farm name exceeds 50 characters or does not exceed 1 character
7	The user does not have permissions. Verify that the Extension Version has the feature in its [claimset].(/docs/intro/permissions)
8	The user does not have the necessary quota in the space.
9	Missing parameters
10	Invalid polygon
11	The field exceeds the ha admitted
12	Incorrect user data
13	The hectares consumed are greater than the user's availability
14	Quota exceeded for desktop, unlimited user
15	User with guaranteed quota, exceeds total available

GET

It allows you to view the fields to which the user has access and information on each one, grouped by farms. In addition, the fields of the users supervised by the user making the request can be viewed, in the case of belonging to a space.

GET /api/getfields

user: Object, fields of the user making the query
- uid: String, Auravant user ID
- user_name: String, user name
- farms: Object[], Array of Objects, being each Object a user farm. See farms-object
supervised: Object, object whose attributes are the IDs of users supervised by the querying user. The value of each attribute is an object with the following attributes:
- uid: String, Auravant user ID.
- user_name: String, user's name
- farms: Object, user farms object. See farms-object

Farm object

The farms object has as attributes the IDs of the farms, and the value of each farm is an object with the following attributes:

id: Int, farm ID
name: String, farm name
tags: Array int, array with farms tag IDs
tags_names: Array Int, array containing the farm labels names
permissions: Array Int, array containing the permissions codes that the user has over the farm permissions codes códigos de los permisos que el usuario tiene sibre el campo
role: Int, user role ID of the user on the farm
bbox: String, WKT (EPSG 4326) of the polygon of the rectangle containing all fields of the farm (Bounding Box).
fields: Object, user farms. See field-object

Field object

The field object has as attributes the IDs of the fields, and the value of each is an object with the following attributes:

id: Int, field ID
name: String, field name
role: Int, User role ID of the user on the field
farm: String, farm name
country: String, country code
shapes: Object
- current: Object
  - polygon: String, WKT (EPSG 4326) of the polygon of the field
  - centroid: String, WKT (EPSG 4326) of the centroid point of the field
  - area: Float, field area in hectares
  - start_date: String, date of field creation in format YYYYY-MM-DD
  - end_date: String, its value is "current", indicating that it is the current form of the field
  - bbox: String, WKT (EPSG 4326) of the polygon of the rectangle containing the field (Bounding Box)

Response Example

In this case, the user "Test User", whose ID is UID-72f1b3cedac245c009de03b7a7c9d5a8, has 2 farms (1975 and 1836). The first has one field (5911) and the second has two (7143 and 7145).

In addition, the user belongs to a space in which it supervises another user ("Test Supervised User", with ID UID-dbaefe8503fe6cdb7909611e8953e74f). This one has a farm (3566) with two fields (13254 y 13289).

{
  "user": {
    "user_name": "Usuario Prueba",
    "uid": "UID-72f1b3cedac245c009de03b7a7c9d5a8",
    "farms": {
      "1975": {
        "name": "Campo Prueba",
        "role": 1,
        "bbox": "POLYGON ((-59.9799656867981 -35.8329711461622, -59.9799656867981 -35.8241463744063, -59.9682283401489 -35.8241463744063, -59.9682283401489 -35.8329711461622, -59.9799656867981 -35.8329711461622))",
        "id": 1975,
        "tags": null,
        "fields": {
          "5911": {
            "name": "Lote 1",
            "role": 1,
            "id": 5911,
            "farm": "Campo Prueba",
            "shapes": {
              "current": {
                "polygon": "POLYGON ((-59.9798798561096 -35.8263037281096, -59.9799656867981 -35.8269822385233, -59.9760818481445 -35.8299919711895, -59.9746897816658 -35.8329711461622, -59.9682283401489 -35.8274867681474, -59.9727773666382 -35.8241463744063, -59.9798798561096 -35.8263037281096))",
                "end_date": "current",
                "area": 5.3809314,
                "centroid": "POINT (-59.974097013473504 -35.82855876028425)",
                "bbox": "POLYGON ((-59.9799656867981 -35.8329711461622, -59.9799656867981 -35.8241463744063, -59.9682283401489 -35.8241463744063, -59.9682283401489 -35.8329711461622, -59.9799656867981 -35.8329711461622))",
                "start_date": "2016-01-01"
              }
            }
          }
        }
      },
      "1836": {
        "name": "Campo Prueba 2",
        "role": 5,
        "bbox": "POLYGON ((-63.4189217537641 -36.89400693295, -63.4189217537641 -36.8893543594351, -63.407678604126 -36.8893543594351, -63.407678604126 -36.89400693295, -63.4189217537641 -36.89400693295))",
        "id": 1836,
        "tags": null,
        "fields": {
          "7143": {
            "name": "Lote Prueba 1",
            "role": 5,
            "id": 7143,
            "farm": "Campo Prueba 2",
            "shapes": {
              "current": {
                "polygon": "POLYGON ((-63.4189217537641 -36.8936626452543, -63.4189082092408 -36.8900518014372, -63.4189195744693 -36.8893543594351, -63.4131949022412 -36.889363476622, -63.4131769760736 -36.8921857020239, -63.4149205684662 -36.8921664236779, -63.4158003330231 -36.8923122931648, -63.4162938594818 -36.8925010650283, -63.4167015552521 -36.8928013829398, -63.4169483184814 -36.8931875042328, -63.4170985221863 -36.893702329585, -63.4189217537641 -36.8936626452543))",
                "end_date": "current",
                "area": 1.4015214,
                "centroid": "POINT (-63.41604936491885 -36.89152834451005)",
                "bbox": "POLYGON ((-63.4189217537641 -36.893702329585, -63.4189217537641 -36.8893543594351, -63.4131769760736 -36.8893543594351, -63.4131769760736 -36.893702329585, -63.4189217537641 -36.893702329585))",
                "start_date": "2016-01-01"
              }
            }
          },
          "7145": {
            "name": "Lote Prueba 2",
            "role": 5,
            "id": 7145,
            "farm": "Campo Prueba 2",
            "shapes": {
              "current": {
                "polygon": "POLYGON ((-63.4077215194702 -36.89400693295, -63.4131650626659 -36.8938535588724, -63.4131938964129 -36.8893632084695, -63.4076980501413 -36.8893752753329, -63.407678604126 -36.8910509419143, -63.4082338213921 -36.8912826202372, -63.4086012840271 -36.8916322815596, -63.4086012840271 -36.8920141184749, -63.4083867073059 -36.8924066791549, -63.407678604126 -36.8928357049116, -63.4077215194702 -36.89400693295))",
                "end_date": "current",
                "area": 22.190903,
                "centroid": "POINT (-63.410436250269456 -36.89168507070975)",
                "bbox": "POLYGON ((-63.4131938964129 -36.89400693295, -63.4131938964129 -36.8893632084695, -63.407678604126 -36.8893632084695, -63.407678604126 -36.89400693295, -63.4131938964129 -36.89400693295))",
                "start_date": "2016-01-01"
              }
            }
          }
        }
      }
    }
  },
  "supervised": {
    "UID-dbaefe8503fe6cdb7909611e8953e74f": {
      "user_name": "Usuario Supervisado de Prueba",
      "uid": "UID-dbaefe8503fe6cdb7909611e8953e74f",
      "farms": {
        "3566": {
          "name": "Campo Ensayo 1",
          "role": 1,
          "bbox": "POLYGON ((-62.6232734075912 -32.8926110237142, -62.6232734075912 -32.8709990515346, -62.5776329389938 -32.8709990515346, -62.5776329389938 -32.8926110237142, -62.6232734075912 -32.8926110237142))",
          "id": 3566,
          "tags": [10, 23],
          "fields": {
            "13254": {
              "role": 1,
              "id": 13254,
              "name": "Lote Ensayo 1",
              "farm": "Campo Ensayo 1",
              "shapes": {
                "current": {
                  "polygon": "POLYGON ((-62.5972237936386 -32.8749998863106, -62.6188531271347 -32.8709990515346, -62.6232734075912 -32.8886830582691, -62.601429497374 -32.8926110237142, -62.5972237936386 -32.8749998863106))",
                  "end_date": "current",
                  "area": 415.523,
                  "centroid": "POINT (-62.61024860061489 -32.8818050376244)",
                  "bbox": "POLYGON ((-62.6232734075912 -32.8926110237142, -62.6232734075912 -32.8709990515346, -62.5972237936386 -32.8709990515346, -62.5972237936386 -32.8926110237142, -62.6232734075912 -32.8926110237142))",
                  "start_date": "2016-01-01"
                }
              }
            },
            "13398": {
              "role": 1,
              "id": 13398,
              "name": "Lote Ensayo 2",
              "farm": "Campo Ensayo 1",
              "shapes": {
                "current": {
                  "polygon": "POLYGON ((-62.5992622724899 -32.8837157945315, -62.5798216215499 -32.8871394523206, -62.5776329389938 -32.8784178739015, -62.5971594206222 -32.8749217936657, -62.5992622724899 -32.8837157945315))",
                  "end_date": "current",
                  "area": 184.64764,
                  "centroid": "POINT (-62.58844760574184 -32.88103062299315)",
                  "bbox": "POLYGON ((-62.5992622724899 -32.8871394523206, -62.5992622724899 -32.8749217936657, -62.5776329389938 -32.8749217936657, -62.5776329389938 -32.8871394523206, -62.5992622724899 -32.8871394523206))",
                  "start_date": "2016-01-01"
                }
              }
            }
          }
        }
      }
    }
  }
}

DELETE

It allows to delete a field, using its ID as a URL parameter.

GET /api/borrarlotes?lote=XXXXXX

NDVI

APIs

GET

It allows to obtain the average NDVI of a field, for a range of dates. The index is calculated from Sentinel 2 imagery. Only images that have been classified as cloud-free are included.

GET /api/fields/ndvi

Parameters in the URL:
- field_id: Required. This is the ID of the field for which you want to query.
- date_from: Optional. Date from which to query. Format YYYYY-MM-DD
- date_to: Optional. Date up to which to query. Format YYYYY-MM-DD

Response Example:

{
    "ndvi": [
        {"date": "2020-06-13", "ndvi_mean": 0.246348},
        {"date": "2020-06-10", "ndvi_mean": 0.215531},
        {"date": "2020-06-08", "ndvi_mean": 0.235166},
        {"date": "2020-06-03", "ndvi_mean": 0.228176},
    ],
    "code": 0,
    "field_id": 1500
}
